Frequently Asked Questions?

​

What materials are E.C. Box India Enclosures made from?

• Fabricated using CRCA draw & G.I. quality sheet steel.

• The door & Enclosure Body were manufactured using CRCA sheet steel.

• Mounting Plate fabricated using G.I. Galvanized Iron.



Which brand of sheet steel?

• We are using TATA / JINDAL steel from authorized suppliers. If required, we will also give necessary test certificates & reports.



What are the different sizes and types of enclosures available?

​

Type – ENCLOSURE BOX / TERMINAL BOX / FORM 1 - ENCLOSURE

​

Enclosure Box Size :

• 50 standard variants Range : (Width x Height x Depth in mm) : 200 x 200 x 150 through 1200 x 1400 x 400

• Starting from 200mm width x 200mm height x 150mm depth to 1200mm width x 1400mm height x 400 depth

​

Terminal Box Size :

• ·24 standard variants Range : (W x H x D in mm) : 150 x 150 x 80 through 800 x 400 x 120

• Starting from 150mm width x 150mm height x 80mm depth to 800mm width x 400mm height x 120 depth

​

Form 1 Enclosure Size :

• 600mm width x 1800mm height x 400mm depth to 1200mm width x 2200mm height x 800mm depth

​

What are the thickness of enclosures available?

​

Enclosure Box Thickness :

•  Body and Door: 1.2mm thickness up to 500 x 500 x 200 and 1.6 mm thickness beyond

• Mounting Plate and Gland plate: 2 mm thickness

Terminal Box Thickness :

• Full range – 1.2 mm thickness

Form 1 Enclosure Thickness :

•   Structure fabricated from 1.6 mm CRCA – 7 fold frame/ back covers & side cover made up of 1.6 mm CRCA

•  The door comprises a 2 mm CRCA standard Foamed-in PU gasket.

•   Mounting plate 2mm thick G.I. as standard & 3mm thickness Powder Coated to RAL- 2000

•  Plinth optional 100mm high fabricated from 2mm Cable entry provision given from the bottom as standard Foamed-in PU gasket.

​

Are E.C. Box India Enclosures compliant with industry standards and certifications?

• C.E. marked certification / U.L. certification under process.



Do the enclosures have pre-drilled holes for mounting components?

• 2 MM mounting plate available



Degree of Protection, Ingress Protection, IP Standard?

• Available in IP65/ IP66

​

How are we achieving this? What s your gasket material?

• Foamed-in PU gasket for superior and long-lasting ingress protection

• The gland plate provided at the bottom for I.P. 65 Customized Solutions



Impact test?

• IK10 protection



What is your powder coating/painting Process:

• Nine tank process



What is your paint colour/shade?

• Powder-coated paint finish Body - RAL 7035 Structure finish

• Mounting plate - Electrogalvanized.



Can I customize an enclosure to fit specific components or requirements?

• Ability to meet special requirements like non-standard sizes, colours, door configuration, and locking arrangement.



Are EC Box India Enclosures suitable for outdoor or harsh environments?

• Yes with Canopy

​

​

​

​
